Data sheet
Regulations
Regulations
CE
Performance
Accuracy (pH)
± 0,02
Accuracy (Temperature)
± 0,5 °C
mv measuring range (max.)
+ 1000
mv measuring range (min.)
- 1000
ORP measuring range (max.)
+ 1000
ORP measuring range (min.)
- 1000
ORP resolution
1 mV
pH measuring range (max.)
+ 14,00
pH measuring range (min.)
0
pH resolution
0,01
Temperature compensation
0,0...100,0 °C
Temperature measuring range (max.)
+ 100,0 °C
Temperature measuring range (min.)
0,0 °C
Temperature resolution
0,1 °C
Working temperature (max.)
+ 45 °C
Working temperature (min.)
0 °C
Feature
Calibration report
Yes
DHS compatible
Yes
Display
Backlight coloured high definition LCD
Inputs
BNC - RCA
IP protection
IP 54
Points of calibration ORP
1
Points of calibration pH
1...3
Stability criteria
3 levels
Standard approved pH
USA - NIST - 2 custom values
Supply
Power supply
100 - 240 V / 50 - 60 Hz
Dimension and Weight
Dimension (LxWxH)
160 x 140 x 45 mm
Weight
380 g
